3.7V 802035 500mAh rechargeable battery lithium polymer battery

Consult immediately
Detail课程目录
Specification

Specification   of Li-Polymer battery LP802035 3.7V 500mah

No.

Item

Characteristics

Remarks

3.1

Nominal Capacity

Minimum:500mAh

Fully charged @1C to 4.2V for 2.5 hrs, then discharge to 3.0V @ 0.2C.

Typical: 500mAh

3.2

Nominal Voltage

3.7V


3.3

Charging Cut-off Voltage

4.2V


3.4

Discharge Cut-off Voltage

3.0V


3.5

Maximum Constant Charging Current

500mA(1.0C)


3.6

Maximum Continuous Discharging Current

1000mA(2.0C)


3.7

Operating Temperature

Charge       0~45


Discharge   –20~60


3.8

Storage Temperature

-20~45 for 1Month


-20~35 for 6Months


3.9

Weight

15.5g

Approximate value

3.1

Storage Voltage

3.80-3.90V


Advantages

1. High energy density: volume energy density can be 460Wh/L
2. Excellent security: no fire, no explore of short-circuit, over-charge, over-discharge, over-current, Shock, vibration, crush, acupuncture.
3. Long cycle lifespan: capacity recovery can be above 80% after 500 cycles
4. High discharge voltage plateau: the 3.6V discharge voltage plateau is more than 42min
5.Environment-friendly: no PB, CD added
6.Flexible size design subject to different space of application
7. Hundreds of moulds for micro size with 10mAh-1000mAh
8. CE/RoHS Directive-compliant/REACH/UL/MSDS/UN38.3/IEC61233 standards.

Application

Communications equipment: mobile phones, PHS phones, Bluetooth cell phones, walkie-talkie
Information equipment: laptop computers, PDA, portable fax machines, printers
Audio-visual equipment: digital cameras, camcorders, portable DVD, VCD players
Others: electric bicycles, miner's lamp
We have more than 400 models Lithium-polymer rechargeable battery for MP3, MP4 players, Bluetooth, GPS, digital phone, PDA, should you have any interest, your inquiry will be highly appreciated802035 500mAH 3.7V   li-polymer prismatic li-ion pouch cell 3.7V  rechargeable lithium battery

Warning

1:Do not expose to dispose of battery in fire
2:Do not disassemble or deform the battery
3:Do not immerse in water
4:Do not put battery nil charge or equipment with wrong terminals connected
5:Do not use battery mixed with other different make/type or model batteries
6:Keep out of reach of children.

Our serviers

1. Provide OEM service, can supports logo or box design
2. Flexible transportation support: we can provide express shipment way or air or sea
3. Small orders are acceptable for great supported
Payment terms can be T/T, L/C or PayPal
4. Within 24 hours reply for both pre-sale and after-sale.

Package&Shipment

1. Standard export carton packaging or Custom-made Package
2. Mode of Transport:   By UPS/DHL/FEDEX/TNT (It takes 3-5 days to arrive).

3: Industrial packing (according to customer's requirements)

802035 500mAH 3.7V   li-polymer prismatic li-ion pouch cell 3.7V  rechargeable lithium battery
